5 KV CLASS HIGH CURRENT BUSHING ASSEMBLIES

60 K.V. BIL., SIDEWALL OR COVER MOUNTED FOR MOUNTING IN 3-3/8" DIA. TANK OPENING

THE RATINGS ARE GIVEN FOR THESE BUSHING ASSEMBLIES ARE BASED ON USE IN AN OUTDOOR LIQUID FILLED TRANSFORMER WITH LOWER END OF BUSHING SUBMERGED UNDER OIL

PART NO

AMPS

STUD SIZE

CONNECTOR TYPE

"A"

"B"

92-9075
92-9076
92-9077

600
800
1000

3/4"-16
1"-14
1-1/8"-12

3/4"-16 TERM POST
1"-14 TERM POST
1-1/8"-12 TERM POST

18"
18"
18"

9-1/4"
9-1/4"
9-1/4"

92-9078
92-9079
92-9080

1200
1600
2000

1-1/4"-12
1-1/2"-12
1-5/8"-12

1-1/4"-12 TERM POST
1-1/2" -12 TERM POST
1-5/8"-12 TERM POST

18"
18"
18"

9-1/4"
9-1/4"
9-1/4"

92-9081
92-9082
92-9083

2600
3200
3600

1-3/4"-12
2"-12
2-1/8"-12

1-3/4"-12 TERM POST
2"-12 TERM POST
2-1/8"-12 TERM POST

18"
18"
18"

9-1/4"
9-1/4"
9-1/8"

92-9085
92-9086
92-9087

2000
2000
2600

1-5/8"-12
1-5/8"-12
1-3/4"-12

4 HOLE SPADE 1/2" THICK
4 HOLE SPADE 3/4"  THICK
4 HOLE SPADE 1/2" THICK

21-1/8"
21-1/8"
21-1/8"

12-3/8"
12-3/8"
12-3/8"

92-9088
92-9089
92-9090

2600
3200
3200

1-3/4"-12
2"-12
2"-12

4 HOLE SPADE 3/4" THICK
4 HOLE SPADE 1/2" THICK
4 HOLE SPADE 3/4" THICK

21-1/8"
21-1/8"
21-1/8"

12-3/8"
12-3/8"
12-3/8"

92-9091
92-9092
92-9095

3200
3600
2000

2-1/8"-12
2-1/8"-12
1-5/8"-12

4 HOLE SPADE 1/2" THICK
4 HOLE SPADE 3/4" THICK
6 HOLE SPADE 1/2" THICK

21-1/8"
21-1/8"
21-1/8"

12-1/4"
12-1/4"
12-3/8"

92-9096
92-9097
92-9098

2000
2600
2600

1-5/8"-12
1-3/4"-12
1-3/4"-12

6 HOLE SPADE 3/4" THICK
6 HOLE SPADE 1/2" THICK
6 HOLE SPADE 3/4" THICK

21-1/8"
21-1/8"
21-1/8"

12-3/8"
12-3/8"
12-3/8"

92-9099
92-9100
92-9101
92-9102

3200
3200
3200
3600

2"-12
2"-12
2-1/8"-12
2-1/8"-12

6 HOLE SPADE 1/2"THICK
6 HOLE SPADE 3/4" THICK
6 HOLE SPADE 1/2" THICK
6 HOLE SPADE 3/4" THICK

21-1/8"
21-1/8"
21-1/8"
21-1/8"

12-3/8"
12-3/8"
12-1/4"
12-1/4"
